| Model | BKW0.8MZ | BKW1.2MZ | BKW1.5MZ | BKW1.8MZ | BKW2.5MZ | BKW3MZA | BKW3MZB | BKW4MZB |
|---|---|---|---|---|---|---|---|---|
| Voltage | 220/1/50 | 380/3/50 | ||||||
| Capacity(W) | 1180 | 1550 | 2160 | 2740 | 3970 | 5560 | 5360 | 6135 |
| Power(HP) | 0.8 | 1.2 | 1.5 | 1.8 | 2.5 | 3 | 3 | 4 |
| Rated Current(A) | 3.6 | 4.7 | 6.1 | 8.1 | 11 | 15.5 | 5.3 | 7.5 |
| Compressor | Embraco SECOP Tecumseh Cubigel HIGHLY | |||||||
| Cooling | Air cooling | |||||||
| Min Storage(m³) | 4 | 8 | 12 | 21 | 30 | 39 | 39 | 52 |
| Max Storage(m³) | 7 | 11 | 21 | 34 | 48 | 65 | 65 | 94 |
* Constant temperature model: +5ºC to -5ºC / Ambient +35ºC / Thickness 100mm / R404A
| Model | BKT1LZ | BKT1.5LZ | BKT2LZ | BKT3.5LZA | BKT3.5LZB | BKT4LZ | BKT5LZ |
|---|---|---|---|---|---|---|---|
| Voltage | 220/1/50 | 380/3/50 | |||||
| Capacity(W) | 1240 | 1600 | 2230 | 3305 | 3215 | 3680 | 6250 |
| Power(HP) | 1 | 1.5 | 2 | 3.5 | 3.5 | 4 | 5 |
| Rated Current(A) | 6 | 7.4 | 10.2 | 13.6 | 6.2 | 8.1 | 9.8 |
| Compressor | Embraco SECOP Tecumseh Cubigel HIGHLY | ||||||
| Cooling | Air cooling / Water Cooling | ||||||
| Min Storage(m³) | 2 | 4 | 9 | 16 | 16 | 22 | 45 |
| Max Storage(m³) | 4 | 8 | 23 | 36 | 36 | 50 | 78 |
* Low temperature model: -15ºC to -25ºC / Ambient +35ºC / Thickness 100mm / R404A
